DISS接头

| DISS系列钢瓶接头 | DISS系列为EP级产品，接头采用优质不锈钢制造，可用于高纯气体、特种气体及医用气体。 | | 特点 | 螺母采用303材料 | | 垫片采用Nickel材料 | | 进气管、堵帽采用316L材料 | | 进气管连接形式有Auto Tube Weld, NPT Male , FSR Male三种可选 |
| 型号参数： |
|
| |
|
|
| | DISS | Modedl No. | Product No. | Outlet Connection | Nipple | Nut | Washer | Cap | | 632 | CGA632-NT4 | 16320 | 1/4" NPT Male | SL-NP-632-NT4 | SS-N-63-00 | NI-G-63 | \ |
| CGA632-TW4 | 16321 | 1/4" Tube Weld | SL-NP-632-TW4 | SS-N-63-00 | NI-G-63 | \ |
| CGA632-VM4 | 16322 | 1/4" FSR Male | SL-NP-632-VM4 | SS-N-63-00 | NI-G-63 | \ |
| CGA632-NT4-SET | 16323 | 1/4" NPT Male | SL-NP-632-NT4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA632-TW4-SET | 16324 | 1/4" Tube Weld | SL-NP-632-TW4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA632-VM4-SET | 16325 | 1/4" FSR Male | SL-NP-632-VM4 | SS-N-63-00 | NI-G-63 | SL-BG-63 | | 634 | CGA634-NT4 | 16340 | 1/4" NPT Male | SL-NP-634-NT4 | SS-N-63-00 | NI-G-63 | \ |
| CGA634-TW4 | 16341 | 1/4" Tube Weld | SL-NP-634-TW4 | SS-N-63-00 | NI-G-63 | \ |
| CGA634-VM4 | 16342 | 1/4" FSR Male | SL-NP-634-VM4 | SS-N-63-00 | NI-G-63 | \ |
| CGA634-NT4-SET | 16343 | 1/4" NPT Male | SL-NP-634-NT4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA634-TW4-SET | 16344 | 1/4" Tube Weld | SL-NP-634-TW4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA634-VM4-SET | 16345 | 1/4" FSR Male | SL-NP-634-VM4 | SS-N-63-00 | NI-G-63 | SL-BG-63 | | 636 | CGA636-NT4 | 16360 | 1/4" NPT Male | SL-NP-636-NT4 | SS-N-63-00 | NI-G-63 | \ |
| CGA636-TW4 | 16361 | 1/4" Tube Weld | SL-NP-636-TW4 | SS-N-63-00 | NI-G-63 | \ |
| CGA636-VM4 | 16362 | 1/4" FSR Male | SL-NP-636-VM4 | SS-N-63-00 | NI-G-63 | \ |
| CGA636-NT4-SET | 16363 | 1/4" NPT Male | SL-NP-636-NT4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA636-TW4-SET | 16364 | 1/4" Tube Weld | SL-NP-636-TW4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA636-VM4-SET | 16365 | 1/4" FSR Male | SL-NP-636-VM4 | SS-N-63-00 | NI-G-63 | SL-BG-63 | | 638 | CGA638-NT4 | 16380 | 1/4" NPT Male | SL-NP-638-NT4 | SS-N-63-00 | NI-G-63 | \ |
| CGA638-TW4 | 16381 | 1/4" Tube Weld | SL-NP-638-TW4 | SS-N-63-00 | NI-G-63 | \ |
| CGA638-VM4 | 16382 | 1/4" FSR Male | SL-NP-638-VM4 | SS-N-63-00 | NI-G-63 | \ |
| CGA638-NT4-SET | 16383 | 1/4" NPT Male | SL-NP-638-NT4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA638-TW4-SET | 16384 | 1/4" Tube Weld | SL-NP-638-TW4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA638-VM4-SET | 16385 | 1/4" FSR Male | SL-NP-638-VM4 | SS-N-63-00 | NI-G-63 | SL-BG-63 | | 640 | CGA640-NT4 | 16400 | 1/4" NPT Male | SL-NP-640-NT4 | SS-N-63-00 | NI-G-63 | \ |
| CGA640-TW4 | 16401 | 1/4" Tube Weld | SL-NP-640-TW4 | SS-N-63-00 | NI-G-63 | \ |
| CGA640-VM4 | 16402 | 1/4" FSR Male | SL-NP-640-VM4 | SS-N-63-00 | NI-G-63 | \ |
| CGA640-NT4-SET | 16403 | 1/4" NPT Male | SL-NP-640-NT4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA640-TW4-SET | 16404 | 1/4" Tube Weld | SL-NP-640-TW4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA640-VM4-SET | 16405 | 1/4" FSR Male | SL-NP-640-VM4 | SS-N-63-00 | NI-G-63 | SL-BG-63 | | 642 | CGA642-NT4 | 16420 | 1/4" NPT Male | SL-NP-642-NT4 | SS-N-63-00 | NI-G-63 | \ |
| CGA642-TW4 | 16421 | 1/4" Tube Weld | SL-NP-642-TW4 | SS-N-63-00 | NI-G-63 | \ |
| CGA642-VM4 | 16422 | 1/4" FSR Male | SL-NP-642-VM4 | SS-N-63-00 | NI-G-63 | \ |
| CGA642-NT4-SET | 16423 | 1/4" NPT Male | SL-NP-642-NT4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA642-TW4-SET | 16424 | 1/4" Tube Weld | SL-NP-642-TW4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| CGA642-VM4-SET | 16425 | 1/4" FSR Male | SL-NP-642-VM4 | SS-N-63-00 | NI-G-63 | SL-BG-63 |
| 1.030-14NGO-RH-INT | Maxmum | Operating Pressure: | 3000 psig |
|
|
| | 712 | CGA712-NT4 | 17120 | 1/4" NPT Male | SL-NP-712-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA712-TW4 | 17121 | 1/4" Tube Weld | SL-NP-712-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA712-VM4 | 17122 | 1/4" FSR Male | SL-NP-712-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA712-NT4-SET | 17123 | 1/4" NPT Male | SL-NP-712-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-71 |
| CGA712-TW4-SET | 17124 | 1/4" Tube Weld | SL-NP-712-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-71 |
| CGA712-VM4-SET | 17125 | 1/4" FSR Male | SL-NP-712-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-71 | | 714 | CGA714-NT4 | 17140 | 1/4" NPT Male | SL-NP-714-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA714-TW4 | 17141 | 1/4" Tube Weld | SL-NP-714-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA714-VM4 | 17142 | 1/4" FSR Male | SL-NP-714-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA714-NT4-SET | 17143 | 1/4" NPT Male | SL-NP-714-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-71 |
| CGA714-TW4-SET | 17144 | 1/4" Tube Weld | SL-NP-714-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-71 |
| CGA714-VM4-SET | 17145 | 1/4" FSR Male | SL-NP-714-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-71 | | 716 | CGA716-NT4 | 17160 | 1/4" NPT Male | SL-NP-716-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA716-TW4 | 17161 | 1/4" Tube Weld | SL-NP-716-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA716-VM4 | 17162 | 1/4" FSR Male | SL-NP-716-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA716-NT4-SET | 17163 | 1/4" NPT Male | SL-NP-716-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-71 |
| CGA716-TW4-SET | 17164 | 1/4" Tube Weld | SL-NP-716-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-71 |
| CGA716-VM4-SET | 17165 | 1/4" FSR Male | SL-NP-716-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-71 | | 718 | CGA718-NT4 | 17180 | 1/4" NPT Male | SL-NP-718-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA718-TW4 | 17181 | 1/4" Tube Weld | SL-NP-718-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA718-VM4 | 17182 | 1/4" FSR Male | SL-NP-718-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA718-NT4-SET | 17183 | 1/4" NPT Male | SL-NP-718-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-71 |
| CGA718-TW4-SET | 17184 | 1/4" Tube Weld | SL-NP-718-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-71 |
| CGA718-VM4-SET | 17185 | 1/4" FSR Male | SL-NP-718-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-71 | | 720 | CGA720-NT4 | 17200 | 1/4" NPT Male | SL-NP-720-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA720-TW4 | 17201 | 1/4" Tube Weld | SL-NP-720-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA720-VM4 | 17202 | 1/4" FSR Male | SL-NP-720-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA720-NT4-SET | 17203 | 1/4" NPT Male | SL-NP-720-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA720-TW4-SET | 17204 | 1/4" Tube Weld | SL-NP-720-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA720-VM4-SET | 17205 | 1/4" FSR Male | SL-NP-720-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-72 | | 722 | CGA722-NT4 | 17220 | 1/4" NPT Male | SL-NP-722-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA722-TW4 | 17221 | 1/4" Tube Weld | SL-NP-722-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA722-VM4 | 17222 | 1/4" FSR Male | SL-NP-722-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA722-NT4-SET | 17223 | 1/4" NPT Male | SL-NP-722-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA722-TW4-SET | 17224 | 1/4" Tube Weld | SL-NP-722-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA722-VM4-SET | 17225 | 1/4" FSR Male | SL-NP-722-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-72 | | 724 | CGA724-NT4 | 17240 | 1/4" NPT Male | SL-NP-724-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA724-TW4 | 17241 | 1/4" Tube Weld | SL-NP-724-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA724-VM4 | 17242 | 1/4" FSR Male | SL-NP-724-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA724-NT4-SET | 17243 | 1/4" NPT Male | SL-NP-724-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA724-TW4-SET | 17244 | 1/4" Tube Weld | SL-NP-724-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA724-VM4-SET | 17245 | 1/4" FSR Male | SL-NP-724-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-72 | | 726 | CGA726-NT4 | 17260 | 1/4" NPT Male | SL-NP-726-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA726-TW4 | 17261 | 1/4" Tube Weld | SL-NP-726-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA726-VM4 | 17262 | 1/4" FSR Male | SL-NP-726-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA726-NT4-SET | 17263 | 1/4" NPT Male | SL-NP-726-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA726-TW4-SET | 17264 | 1/4" Tube Weld | SL-NP-726-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA726-VM4-SET | 17265 | 1/4" FSR Male | SL-NP-726-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-72 | | 728 | CGA728-NT4 | 17280 | 1/4" NPT Male | SL-NP-728-NT4 | SS-N-70-00 | NI-G-63 | \ |
| CGA728-TW4 | 17281 | 1/4" Tube Weld | SL-NP-728-TW4 | SS-N-70-00 | NI-G-63 | \ |
| CGA728-VM4 | 17282 | 1/4" FSR Male | SL-NP-728-VM4 | SS-N-70-00 | NI-G-63 | \ |
| CGA728-NT4-SET | 17283 | 1/4" NPT Male | SL-NP-728-NT4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA728-TW4-SET | 17284 | 1/4" Tube Weld | SL-NP-728-TW4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| CGA728-VM4-SET | 17285 | 1/4" FSR Male | SL-NP-728-VM4 | SS-N-70-00 | NI-G-63 | SL-BG-72 |
| 1.125-14NGO-RH-INT | Maxmum | Operating Pressure: | 3000 psig |
|
|
|
|
